Al Vishwas Nickel Alloys is a reliable manufacturer and supplier located in Dubai, UAE, providing high-performance Alloy C263 Sheets and Plates to industries that need materials with outstanding strength and resistance to heat. Recognized for their dedication to quality, precision, and customer-focused service, the company delivers products designed to endure challenging conditions. Their Alloy C263 Sheets and Plates are made through advanced manufacturing methods and rigorous quality inspections, guaranteeing reliability, durability, and consistency. Backed by a solid history of on-time delivery and technical know-how, Al Vishwas Nickel Alloys serves a broad spectrum of applications across aerospace, chemical processing, and high-temperature industrial sectors.



Table of Contents

Alloy C263 Sheets Manufacturer in Dubai, Alloy C263 Alloy Cold Rolled Sheets in Abu Dhabi, Alloy C263 Perforated Sheet in Sharjah, Nimonic C263 Alloy Plates Supplier in Ajman, Alloy C263 2B Finish Plates in Jebel Ali, Alloy C263 Alloy Polished Plates Supplier in Dubai, Alloy C263 Clad Sheets Distributor in Abu Dhabi, Alloy C263 Plates Size Chart, AMS 5872 Alloy C263 Plates, Alloy C263 Sheet and Plate Exporter in Abu Dhabi

Alloy C263 Sheets and Plates are produced from a nickel-cobalt-chromium-molybdenum superalloy engineered for outstanding mechanical strength and resistance to oxidation at high temperatures. The alloy uses nickel as its base element, together with chromium for corrosion resistance, cobalt for hardness, and molybdenum to boost strength and stability. These products deliver high tensile and creep strength, superb fatigue resistance, and robust thermal stability. Alloy C263 keeps its integrity in harsh environments and withstands oxidation and stress-corrosion cracking, which makes it well suited for applications that demand lasting structural performance under extreme heat and pressure.



Alloy C263 Sheets and Plates Specifications

Standard Specification : AMS 5872
Dimensions : AMS
Sheets Thickness : Range from .008″ to .0125″
Plates Thickness : Ranges from .0125″ to 5.00″
Sheets/Plates Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Sheets/Plates Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Tempers : Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Value Added Service : Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc.

Alloy C263 Sheets and Plates Chemical Composition

Grade Ni Co Cr Mo Ti Fe Mn Al Si Cu C B S
Alloy C263 49 19-21 19-21 5.60-6.10 1.90-2.40 0.70 0.60 0.60 0.40 0.20 0.040 – 0.080 0.0050 0.0070

Alloy C263 Sheets and Plates Mechanical Properties

Material Temp °C Yield Strength (Mpa) Tensile Strength (Mpa) Elongation % Hardness HRC
Alloy C263 Solution Treated (AMS 5872 / BS HR206) RT 22.5 max
Alloy C263 Heat Treated (AMS 5872 / BS HR206 RT 580 (typical) 973 (typical) 39 –
Alloy C263 Heat Treated (AMS 5872 / BS HR206 780 403 (min) 541 (min) 9

Alloy C263 2B Finish Plates in Ajman, Alloy C263 Polished Sheets Supplier in Dubai, Nimonic C263 Perforated Sheet Weight Chart, Alloy C263 Alloy Hot Rolled Plate Manufacturer in Abu Dhabi, Alloy C-263 Plate, Nimonic Alloy C263 Sheets and Plates Manufacturer in Sharjah, Alloy C-263 CR Sheet, Alloy C263 Shim Sheet Price List in Sharjah, Suppliers of Alloy C263 Clad Sheets in Jebel Ali, Alloy C263 Cold Rolled Plate Available in All Sizes and Material Grades in Ajman.

ISO Certified

Largest Inventory

On Time Deliveries

Customer Support

Largest Manufacturer and Supplier of Alloy C263 Sheets and Plates in Dubai, UAE

At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Alloy C263 Sheets and Plates in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our modern production facilities are strategically situated in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of high-quality materials on hand and ready for immediate supply. We are committed to providing outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.

Types of Alloy C263 Sheets and Plates

Alloy C263 Clad Plates
Alloy C263 Perforated Plates
Alloy C263 CR Sheet
Alloy C263 2B Finish Plates
Alloy C263 HR Sheet
Alloy C263 Shim Sheets

Reach out to us for a fast quote tailored to your needs.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Alloy C263 Sheet in Jebel Ali, Alloy C263 Plates Price List in Dubai, Alloy C263 2B Finish Plates Supplier in Abu Dhabi, AMS 5872 Alloy C263 HR Plate, Alloy C263 Chequered Plates Price List in Sharjah, Alloy C263 Alloy Polished Plates Manufacturer in Ajman, Alloy C263 Perforated Plates in Jebel Ali, Alloy C263 Shim Sheet Suppliers in Sharjah, Alloy C263 Sheet and Plate Suppliers in Dubai, UAE.

Alloy C263 Sheets and Plates Uses

Alloy C263 Sheets and Plates are extensively utilized across industries that function in high-temperature and corrosive conditions. They find frequent use in aerospace engineering for turbine parts, combustion chambers, exhaust systems, and other engine components exposed to intense heat. Within industrial applications, the alloy serves in furnace parts, heat-treatment fixtures, and thermal insulation systems owing to its outstanding stability. Chemical processing plants depend on Alloy C263 for equipment subjected to corrosive gases and high temperatures. Its exceptional strength and resistance to oxidation also render it appropriate for energy generation, marine engineering, and advanced mechanical systems that demand reliable long-term performance.
