Al Vishwas Nickel Alloys, located in Dubai, UAE, is your dependable supplier of premium Copper Nickel Sheets and Plates. Valued for their outstanding corrosion resistance and durability, our Copper Nickel products are ideal for challenging marine and industrial settings. Through accurate manufacturing and strict quality control, we guarantee that our sheets and plates satisfy the highest industry benchmarks. Select Al Vishwas Nickel Alloys for dependable performance and remarkable longevity in your vital applications.
Copper-nickel sheets and plates generally consist of 90% copper and 10% nickel. This alloy delivers high corrosion resistance, particularly in seawater, and offers excellent thermoelectric conductivity. Among its mechanical properties are high strength and outstanding resistance to stress fracture. Blending copper with nickel yields both durability and corrosion resistance. Furthermore, copper-nickel alloys deliver superb formability and can withstand high temperatures, which makes them well suited for marine applications, heat exchangers and industrial equipment.
| Specifications | ASTM B171, B122 / ASME SB171, SB122 |
| Standards | ASTM, ASME and API |
| Size | 1 mm to 100 mm |
| Finishing | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coils, Foils, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) & Angle, Channel, Tray, Roll Etc. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | UNS NO. C92200 & UNS NO. C83600, UNS NO. C70600 ( CU -NI- 90/10), C71500 ( CU -NI- 70/30), UNS NO C10100, C10200, C10300, C10800, C12000, C12200. |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
|---|---|---|---|---|---|---|
| Cupro Nickel | 88.6 min | 1.0 max | 0.05 max | 9-11 max | 1.8 max | 1 max |
| Element | Copper Nickel 90/10 |
|---|---|
| Density | 8.1 g/cm3 |
| Melting Point | 1443 °C (2430 °F) |
| Tensile Strength | Psi -80,000, MPa -551 |
| Yield Strength (0.2%Offset) | Psi – 35,000, MPa – 241 |
| Elongation | 30 % |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel Sheet and Plates in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our cutting-edge production facilities are strategically situated in the UAE, enabling us to keep an extensive inventory of more than 16,000 tons of top-quality materials on hand and ready in stock. We are committed to providing outstanding products and services, guaranteeing dependability and excellence for our clients worldwide.
Reach out to us for a fast quote on your requirement.
Copper-nickel sheets and plates are extensively utilized in marine settings owing to their outstanding resistance to seawater corrosion. They are frequently seen in shipbuilding, offshore platforms and desalination plants. Additionally, these alloys serve in heat exchangers, dense tubes, and numerous industrial uses where corrosion resistance and high thermal conductivity matter Their toughness and strength render them well-suited for chemical processing, power generation and aerospace component uses, for dependable performance in needed under conditions.
