Aluminium Bronze Sheets and Plates Manufacturer in Dubai, UAE

Home > Aluminium Bronze Sheets and Plates

Al Vishwas Nickel Alloys is a reliable manufacturer and supplier located in Dubai, UAE, recognized for providing high-quality Aluminium Bronze Sheets and Plates to industries with challenging performance needs. The company concentrates on supplying durable, precision-engineered materials that comply with international standards and offer lasting dependability. Their Aluminium Bronze Sheets and Plates are produced through advanced processes, guaranteeing outstanding strength, corrosion resistance, and dimensional accuracy. With a dedication to customer satisfaction, on-time delivery, and tailored solutions, Al Vishwas Nickel Alloys continues to serve a broad range of industrial applications, making them a trustworthy partner for the engineering, marine, and manufacturing sectors.

Aluminium Bronze Sheets Manufacturer in Dubai, Aluminium Bronze Alloy Cold Rolled Sheets in Abu Dhabi, Aluminium Bronze Perforated Sheet in Sharjah, Aluminium Bronze Plates Supplier in Ajman, Aluminum Bronze 2B Finish Plates in Jebel Ali, Aluminum Bronze Alloy Polished Plates Supplier in Dubai, Aluminum Bronze Clad Sheets Distributor in Abu Dhabi, Aluminium Bronze Plates Size Chart, Aluminium Bronze Sheet and Plate Exporter in Abu Dhabi

Aluminium Bronze Sheets and Plates consist mainly of copper, with aluminium serving as the principal alloying element, frequently mixed with modest quantities of iron, nickel, or manganese to boost performance. This makeup improves strength, wear resistance, and corrosion resistance, particularly in marine and chemical settings. The material delivers high tensile strength, outstanding fatigue resistance, and good hardness while retaining solid ductility. Aluminium Bronze also holds up well under heavy loads and high temperatures, making it well suited for demanding applications where durability, stability, and lasting mechanical reliability are critical.

Aluminium Bronze Sheets and Plates Specifications

Specifications	ASTM B505 / ASME SB505, BS EN 10088-2, en 10028-7, IS 6911, AMS 4640, UNS C63000, UNS C95800, UZ19AL6, UNS C95510, AMS 4880
Dimensions	MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc
Size Range	Cold Rolled : 0.5-6.4 mm Hot Rolled : 3.0–10.0 mm
Width	1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length	2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness	0.3 mm to 120 mm
International Standard of Sheets	ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510
Tolerances (width / thickness)	EN 10258/ DIN 59381 EN 10151 EN 10088
Finish	2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, mirror etc.
Hardness	Half Hard, Soft, Hard, Quarter Hard, Spring Hard
Form	Sheet, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, soft annealed, descaled, sheared, annealed
Value Added Service	Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc.
Profiling	Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting

Aluminium Bronze Sheets and Plates Chemical Composition

Alloy	Aluminium	Iron	Nickel	Manganese	Zinc	Arsenic
CuAl5	4.0–6.5%	0.5% max.	0.8% max.	0.5% max.	0.5% max.	0.4% max.
CuAl8	7.0–9.0%	0.5% max.	0.8% max.	0.5% max.	0.5% max.
CuAl8Fe3	6.5–8.5%	1.5–3.5%	1.0% max.	0.8% max.	0.5% max.
CuAl9Mn2	8.0–10.0%	1.5% max.	0.8% max.	1.5–3.0%	0.5% max.
CuAl10Fe3	8.5–11.0%	2.0–4.0%	1.0% max.	2.0% max.	0.5% max.
CuAl10Fe5Ni5	8.5–11.5%	2.0–6.0%	4.0–6.0%	2.0% max.	0.5% max.

Aluminium Bronze Sheets and Plates Mechanical Properties

Properties	Metric	Imperial
Hardness, Rockwell C	27	27
Tensile strength (M30 and O61 tempers)	690 MPa	100000 psi
Yield strength (M30 and O61 tempers)	380 MPa	55100 psi
Elongation at break (in 50 mm, 1% reduction in area)	1.00%	1.00%
Elastic modulus	117 GPa	17000 ksi
Compressive yield strength (at permanent set of 0.1%)	450 MPa	65300 psi
Compressive yield strength (at permanent set of 1%)	880 MPa	128000 psi
Poisson’s ratio	0.34	0.34
Charpy impact (@ 18.0 – 100°C/ -0.400 – 212°F, keyhole)	3.00 J	2.21 ft-lb
Izod impact (@ 18.0 – 100°C/ -0.400 – 212°F)	3.00 J	2.21 ft-lb
Fatigue strength (@# of cycles 1.00e+8, M30 temper)	460 MPa	66700 psi
Machinability (UNS C36000 (free-cutting brass) = 100)	20	20
Shear modulus	42.3 GPa	6140 ksi

ASME SB 271 Aluminium Bronze Plates in Jebel Ali, Aluminum Bronze Plates Price List in Dubai, Aluminium Bronze 2B Finish Plates Supplier in Abu Dhabi, Aluminium Bronze Chequered Plates Price List in Sharjah, Aluminum Bronze Alloy Polished Plates Manufacturer in Ajman, Aluminium Bronze Perforated Plates in Jebel Ali, Aluminum Bronze Shim Sheet Suppliers in Sharjah, Aluminum Bronze AMS 4880 Sheet and Plate Suppliers in Dubai, UAE.

ISO Certified

Largest Inventory

On Time Deliveries

Customer Support

Largest Manufacturer and Supplier of Aluminium Bronze Sheets and Plates in Dubai, UAE

At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Aluminium Bronze Sheets and Plates in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our cutting-edge production facilities are strategically situated in the UAE, enabling us to keep an extensive inventory of more than 16,000 tons of top-quality materials on hand in stock. We are committed to supplying outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.

Types of Aluminium Bronze Sheets and Plates

Reach out to us for a fast quote tailored to your requirement.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

ASTM B169 Aluminium Bronze 2B Finish Plates in Ajman, Aluminium Bronze Polished Sheets Supplier in Dubai, Aluminum Bronze Perforated Sheet Weight Chart, Aluminium Bronze Alloy Hot Rolled Plate Manufacturer in Abu Dhabi, Aluminium AMS 4640 Bronze Sheets and Plates Manufacturer in Sharjah, Aluminum Bronze BA Finish Plates Price List in Sharjah, Suppliers of Aluminium Bronze Clad Sheets in Jebel Ali, Aluminium Bronze Cold Rolled Plate Available in All Sizes and Material Grades in Ajman.

Aluminium Bronze Sheets and Plates Uses

Aluminium Bronze Sheets and Plates find broad use across industries that demand tough, corrosion-resistant materials. Because of their outstanding resistance to saltwater corrosion, they are frequently used in marine hardware, shipbuilding components, propeller parts, and seawater handling systems. Within industrial environments, they serve in bushings, bearings, valve components, and heavy-duty mechanical parts subjected to friction and wear. The alloy is also employed in chemical processing equipment, aerospace components, and architectural elements where strength and durability matter. Owing to their distinctive blend of mechanical performance and corrosion resistance, Aluminium Bronze Sheets and Plates fulfill both functional and structural purposes across numerous sectors.
