Home > Copper Nickel > Copper Nickel Wire
Al Vishwas Nickel Alloys, based in Dubai, UAE, distinguishes itself as a leading manufacturer and supplier of Copper Nickel Wires, providing high-quality products designed for industrial, marine, and electrical applications. These wires are engineered for outstanding corrosion resistance, remarkable conductivity, and strong mechanical strength, guaranteeing they satisfy rigorous international standards for reliability and performance. With a firm emphasis on precision manufacturing and comprehensive quality control, Al Vishwas Nickel Alloys ensures uniform and long-lasting products. Copper Nickel Wires are ideal for seawater systems, chemical plants, electrical components, and marine engineering, delivering enduring performance even in harsh environments where they encounter saline, corrosive chemicals, and elevated temperatures.
Copper Nickel Wires are generally made up of either 90% copper and 10% nickel (CuNi 90/10) or 70% copper and 30% nickel (CuNi 70/30), along with minor additions of iron and manganese. This alloy is recognized for its outstanding corrosion resistance, especially in seawater and harsh chemical environments. It also offers superb tensile strength, flexibility, ductility, and resistance to fatigue. The wires hold their form under thermal stress and display good electrical and thermal conductivity. Their combination of mechanical strength and corrosion resistance makes them a dependable option for tough marine, chemical, and industrial applications.
| Specifications | ASTM B206, ASME SB206 | |
|---|---|---|
| Copper Nickel Wire Grades | 90/10 Copper Nickel Wire, 70/30 Copper Nickel Wire (Cuni 90/10 & Cuni 70/30) | |
| Copper Nickel Wire Dimensions | ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360 | |
| Copper Nickel Wire Length | 100 mm TO 6000 mm, customizable | |
| Copper Nickel Wire Diameter | 10 mm To 100 mm or as per client requirement | |
| Copper Nickel Wire Main Types |
| |
| Copper Nickel Wire Density | 8.89 g/cm3 | |
| 580-750 | |
| as standard | |
| 28-30 | |
| Surface | Polished bright, Smooth | |
| Copper Nickel Wire Technique | Cold Rolled, hot rolled | |
| Copper Nickel Wire Condition | M, Y, 1/2Hard | |
| Tempers | Tempers range from dead soft annealed to ultra spring temper | |
| Copper Nickel welded wire mesh | Roll Width: 24inch, 36inch, 1Metre, 48inch, 72inch, or 84inch Roll Length: 100feet or 150feet | |
| Copper Nickel wire mesh weaving methods | plain weave, twill weave, dutch weave | |
| Offered in a wide range of packages including: |
|
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cu-Ni 70-30 | 65.0 min | 1 max | .05 max | 29-33 | 0.4-1.0 | 1 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.89 g/cm3 | 2260 F | 50000 psi | 20000 psi | 30 % |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel Wire in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our modern manufacturing facilities are strategically positioned in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of top-quality materials available on hand. We are committed to supplying outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your requirement.
Copper Nickel Wires are widely applied across numerous industries that require strong corrosion resistance and reliable electrical or mechanical performance. Within marine environments, they serve in seawater systems, desalination facilities, and shipbuilding for wiring and connections subjected to salty conditions. The chemical and petrochemical industries depend on them for process instrumentation, control systems, and electrical connections in corrosive settings. They are equally well-suited for heat exchangers, delivering efficiency and durability in demanding applications.
