Al Vishwas Nickel Alloys distinguishes itself as a dependable manufacturer and supplier of premium Hastelloy C22 Tubing, offering high-performance, corrosion-resistant alloy products to a range of industries in Dubai, UAE. Recognized for their engineering excellence and commitment to quality, the company manufactures Hastelloy C22 Tubing capable of withstanding aggressive chemicals, elevated temperatures, and demanding industrial environments. Every tube is produced with rigorous quality control to ensure exceptional durability, reliability, and an extended service life. Serving sectors such as chemical processing, petrochemical, pharmaceuticals, marine, and pollution control, Al Vishwas Nickel Alloys delivers tubing solutions that comply with global standards and reliably support critical applications.
| Inconel Tube Standards | ASTM B622, ASTM B775, ASTM B619, ASTM B626, ASTM B516, ASTM B751 |
|---|---|
| International Specification | din 17751, ISO 6207 |
| Astm B626 Nickel Alloy C22 Welded Tube Size | 6.35 mm To 152 mm OD |
| Astm B622 Hastelloy C22 Seamless Tubing Size | 3.35 mm To 101.6 mm OD |
| Sb 444 Uns N06022 Tubing wall thickness | 0.020″ –0.220″, (custom wall thicknesses available) |
| Astm B622 Hastelloy C22 Tubing Swg & Bwg | 12 Swg., 10 Swg., 16 Swg., 14 Swg., 20 Swg., 18 Swg. |
| Tube Length | Standard & Cut length, Double Random, Single Random Tube |
| Types of Hastelloy C22 Tube | ERW, Seamless, Welded, Fabricated, EFW Tube / Tubing |
| Form | ‘ Hollow, U’ bent, LSAW, Hydraulic, Straight Tube, Boiler, Round, Tube Coil, Square, Rectangular Etc |
| Ams 5581 Tubing Finish | AP (Annealed & Pickled), Polished, MF, BA (Bright & Annealed) |
| Marking | All Hastelloy C22 Tubing are marked as follows: Grade, Standard, Thickness, OD, Heat No., Length (Or according to the customer’s request.) |
| NCF 625 tube End | Beveled End, Plain End, Treaded Tube |
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C22 | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy C22 Tubing in Dubai, UAE, delivering advanced solutions for every piping requirement you have. Our modern manufacturing facilities are strategically situated in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of top-quality materials available on hand. We are committed to supplying outstanding products and services, guaranteeing dependability and excellence for our clients around the world.
Reach out to us for a fast quote tailored to your requirement.
Hastelloy C22 Tubing is well suited to industries requiring exceptional corrosion resistance and dependable performance in extremely harsh environments. Within chemical processing facilities, it serves to handle concentrated acids, chlorides, and blended chemical solutions. The petrochemical and oil and gas industries rely on it for reactors, pipelines, and high-temperature systems exposed to corrosive fluids. In the pharmaceutical field, it plays a vital role in equipment that has to endure severe conditions while maintaining safety and efficiency. All in all, Hastelloy C22 Tubing remains a preferred option for applications where durability and reliability cannot be compromised.
