Al Vishwas Nickel Alloys is a dependable manufacturer and supplier of Haynes 230 Sheets and Plates located in Dubai, UAE. They offer premium high-temperature alloy products built for demanding industrial applications. Well-known for their outstanding strength, oxidation resistance, and stability under high temperatures, Haynes 230 is a preferred option in sectors such as aerospace, chemical processing, and power generation. Al Vishwas Nickel Alloys takes pride in precision manufacturing, strict quality control, and on-time delivery, making sure they satisfy both international standards and the particular requirements of their clients. Their Haynes 230 sheets and plates are recognized for their exceptional reliability, extended service life, and steady performance, which makes them well-suited for critical engineering tasks.
| Specification : | AMS 5878 |
| Standard : | AMS, AMS, API |
| Specialize sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Size : | 0.5 MM TO 200 MM THICK IN 1000 MM TO 2500 MM WIDTH & 2500 MM TO 12500 MM LENGTH |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Haynes 230 (UNS N06230) |
| Weight% | C | Mn | Si | P | S | Cr | Co | Fe | Al | Ti | B | Cu | La | W | Mo | Ni |
| Haynes 230 | 0.05-0.15 | 0.30-1.0 | 0.25-0.75 | 0.03 | 0.015 | 20.0-24.0 | 5.0 | 3.0 | 0.20-0.50 | 0.10 | 0.015 | 0.50 | 0.005-0.05 | 13.0-15.0 | 1.0-3.0 | Rem |
| Material | Test Temp °F | Ultimate Tensile Strength | 0.2 % Yield Strength | Elongation in % | Hardness HB |
| Haynes Alloy 230 Extruded Bar Solution Treated (AMS 5891) | RT | 758 Mpa 110 ksi | 310 Mpa 45 ksi | 35 | 241 max |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Sheets and Plates in Dubai, UAE, delivering advanced solutions for every piping requirement you have. Our modern manufacturing facilities are strategically positioned in the UAE, enabling us to keep a large inventory of more than 16,000 tons of top-grade materials available in stock. We are committed to supplying outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your needs.
Haynes 230 Sheets and Plates are widely applied in situations that call for strength at high temperatures and resistance to oxidation. Within the aerospace industry, they serve in combustion cans, transition ducts, and heat shields. For power generation, these materials play a vital role in gas turbine components, burner parts, and high-temperature ducts. Chemical processing plants rely on Haynes 230 for furnace hardware, reactor internals, and high-temperature structural parts exposed to corrosive environments. The alloy’s exceptional thermal stability makes it a dependable option for a range of demanding applications.
