Al Vishwas Nickel Alloys, headquartered in Dubai, UAE, is a trusted manufacturer and supplier of Inconel 601 Wire, purpose-built for high-temperature and severely corrosive settings. Crafted from premium-grade Inconel 601 alloy, this wire delivers outstanding oxidation resistance, thermal stability, and mechanical strength, guaranteeing dependable performance even under the harshest conditions. Al Vishwas’s Inconel 601 Wire is used across a range of industries, including the aerospace, power generation, chemical, and petrochemical sectors. Precisely engineered to satisfy strict quality standards, it provides durability, flexibility, and steady performance. This wire is ideal for applications requiring resistance to scaling, corrosion, and thermal degradation, delivering efficient, long-lasting solutions.
Inconel 601 Wire consists primarily of nickel, chromium, and small quantities of iron, which lend it remarkable mechanical properties and resistance to oxidation under high temperatures. The alloy demonstrates strong tensile and yield strength, creep resistance, and steadiness throughout thermal cycling. Because it can withstand carburization and oxidation, it holds up its performance in both oxidizing and reducing environments. Such mechanical and thermal qualities make Inconel 601 Wire a superb option for critical applications that demand long-term durability, structural integrity, and outstanding performance under extreme conditions.
| Specifications | ASTM B166 ASME SB166, AMS | |
|---|---|---|
| SB 166 UNS N06601 Wires Dimensions | ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360 | |
| Alloy 601 Wires Length | 100 mm TO 6000 mm, customizable | |
| ASTM B166 UNS N06601 Wires Diameter | 10 mm To 100 mm or as per client requirement | |
| 2.4851 Alloy 601 Wires Main Types |
|
|
| Alloy 601 UNS N06601 Wires Density | 8.89 g/cm3 | |
|
580-750 | |
|
as standard | |
|
28-30 | |
| Surface | Polished bright, Smooth | |
| Inconel N06601 Wires Technique | Cold Rolled, hot rolled | |
| Din 2.4851 Wires Condition | M, Y, 1/2Hard | |
| Tempers | Tempers range from dead soft annealed to ultra spring temper | |
| Inconel 601 welded wire mesh | Roll Width: 24inch, 36inch, 1Metre, 48inch, 72inch, or 84inch Roll Length: 100feet or 150feet | |
| SB 166 UNS N06601 wire mesh weaving methods | plain weave, twill weave, dutch weave | |
| Offered in a wide range of packages including |
|
|
| Sample | Free sample | |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | ||
| Grade | C | Mn | Si | Cu | S | Cr | Fe | Ni | N |
| Inconel 601 | 0.10 max | 1.00 max | 0.50 max | 1.00 max | 0.015max | 21.00 – 25.00 | bal | 58.0-63.0 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 601 Wire in Dubai, UAE, we deliver innovative solutions for every one of your piping requirements. Our advanced manufacturing facilities are strategically situated in the UAE, enabling us to keep an extensive inventory of more than 16,000 tons of top-quality materials always available in stock. We are committed to supplying outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your needs.
You’ll find Inconel 601 Wire commonly applied in industrial furnaces, heating elements, thermocouples, gas turbines, and high-temperature chemical processing equipment. It works well for welding, forming, and fabrication processes that demand high strength and resistance to oxidation. Industries rely on Al Vishwas’s Inconel 601 Wire to produce long-lasting heating coils, resistance wire, and components capable of enduring severe thermal and corrosive conditions. Its application delivers minimal maintenance, improved safety, and an extended service life in demanding environments, making it an essential material for high-performance engineering and industrial solutions.
