Al Vishwas Nickel Alloys, headquartered in Dubai, UAE, is a trusted manufacturer and supplier of Inconel 617 Forged Fittings. These high-quality fittings are precisely engineered from Inconel 617, a nickel-chromium-cobalt-molybdenum alloy prized for its exceptional strength, oxidation resistance, and thermal stability even under high temperatures. Al Vishwas’s forged fittings are recognized for their superior durability, dependability, and corrosion resistance, making them ideal for the most demanding industrial applications. Valued for their precision and long service life, these Inconel 617 Forged Fittings serve a vital function in industries such as power generation, chemical processing, aerospace, and petrochemicals, where reliable performance under extreme conditions is essential.
Inconel 617 Forged Fittings are primarily made up of nickel, chromium, and cobalt, along with extra molybdenum and iron to enhance strength and corrosion resistance. This alloy offers superb mechanical properties, such as high tensile strength, creep resistance, and remarkable oxidation stability at high temperatures. The forging process improves toughness, structural integrity, and dimensional precision, guaranteeing that these fittings can withstand thermal cycling, demanding environments, and high-pressure conditions without bending or fracturing. Thanks to these traits, Inconel 617 Forged Fittings are a dependable and long-lasting option for essential industrial systems.
| Standards | ASTM B564/ ASME SB564 |
| Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Forged Fittings Thread | NPT, BSPT, BSPP |
| Forged Fittings Test Certificates |
|
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs |
| C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 617 Forged Fittings in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our modern production facilities are strategically situated in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of top-quality materials on hand and ready to ship. We are committed to providing outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your requirement.
Inconel 617 Forged Fittings are commonly found in gas turbines, nuclear reactors, chemical processing equipment, and heat exchangers. They work exceptionally well in high-temperature and corrosive environments, including furnace components, boiler systems, and petrochemical pipelines. Their remarkable resistance to thermal fatigue, oxidation, and stress corrosion cracking ensures durable performance with reduced maintenance. Sectors that value reliability and safety under extreme conditions choose Al Vishwas Nickel Alloys’ Inconel 617 Forged Fittings for efficient, long-lasting, and high-performing solutions.
