Al Vishwas Nickel Alloys, headquartered in Dubai, UAE, is a well-regarded manufacturer and supplier of high-quality Inconel 718 Forged Fittings. These fittings are designed to perform exceptionally in high-temperature, high-pressure, and corrosive environments. Through careful workmanship, they deliver remarkable strength, durability, and resistance to oxidation and corrosion, while conforming to rigorous international standards. Al Vishwas Nickel Alloys is dedicated to providing steady quality and dependability, which makes their Inconel 718 Forged Fittings ideal for essential industrial uses. Recognized for their ruggedness, these fittings are widely used across the aerospace, petrochemical, power generation, and marine industries, where performance and safety matter greatly.
Inconel 718 Forged Fittings are primarily composed of nickel, chromium, and iron, along with additional elements such as niobium, molybdenum, aluminum, and titanium that enhance their mechanical strength. These fittings demonstrate excellent tensile, yield, and creep-rupture strength even under high temperatures. They likewise provide outstanding resistance to oxidation, pitting, and stress-corrosion cracking. The alloy retains strong toughness, dimensional stability, and formability, permitting accurate forging and welding. This distinctive blend of characteristics guarantees that Inconel 718 Forged Fittings can be depended upon in high-pressure, corrosive, and high-temperature settings, delivering lasting durability and structural integrity for demanding industrial applications.
Specifications :ASTM B564 / ASME SB564
Dimensions :ASME B16.11, MSS-SP-79, MSS-SP-83, MSS-SP-95, MSS-SP-97, BS3799
Size :1/8″ NB up to 4″ NB (Socketweld & Screwed-Threaded)
Type :Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure :Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | C | Mn | Si | P | S | Cr | Cu | Ni | Fe |
| Inconel 718 | 0.08 max | 0.35 max | 0.35 max | – | 0.015 max | 17 – 21 | 0.30 max | 50.0-55.0 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.2 g/cm3 | 1350 °C (2460 °F) | Psi –1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 718 Forged Fittings in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our modern production facilities are strategically situated in the UAE, enabling us to keep an extensive inventory of more than 16,000 tons of top-quality materials readily on hand in stock. We are committed to providing outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us to receive a fast quote for your needs.
Inconel 718 Forged Fittings are frequently used in aerospace applications, such as engine parts, exhaust systems, and high-temperature ducting. Within the power generation sector, they serve in turbines, boilers, and heat exchangers to endure severe thermal and mechanical loads. The oil, gas, and petrochemical industries depend on these fittings for high-pressure pipelines, reactor vessels, and chemical processing systems. Their outstanding corrosion resistance also makes them well-suited for marine and offshore uses, like seawater systems.
