Al Vishwas Nickel Alloys, a well-regarded manufacturer and supplier based in Dubai, UAE, focuses on premium Invar 36 Sheets and Plates crafted for industries that require outstanding dimensional stability. Known for its exceptionally low coefficient of thermal expansion, Invar 36 is ideal for precision applications where temperature variations can impact performance. Al Vishwas Nickel Alloys ensures superior product consistency, strict quality control, and compliance with international manufacturing standards. Their Invar 36 Sheets and Plates deliver dependability, precision, and an extended service life in demanding conditions. Dedicated to excellence, the company supplies the aerospace, instrumentation, electronics, and tooling sectors with materials engineered to satisfy exacting technical specifications.
Invar 36 Sheets and Plates consist primarily of 36% nickel, with iron making up the balance, producing an alloy renowned for its exceptionally low thermal expansion. This material delivers solid mechanical strength, remarkable toughness, and reliable performance over a wide temperature range. It preserves dimensional accuracy despite thermal changes and provides moderate corrosion resistance. Invar 36 features a tensile strength of roughly 70 ksi and high ductility, which makes it easy to fabricate. Its capacity to retain structural integrity while limiting thermal movement makes it a superb option for precision-engineered components and temperature-sensitive assemblies.
| Standards : | ASTM F1684 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc |
| Grade | C | Mn | Si | S | Co | Fe | Mo | Al |
| Invar 36 | .008 max | .30 max | .15 max | .001 max | .35 max | 63.0 max | .02 max | .03 max |
| Element | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Invar 36 | KSI (MPa) 63 / (430) Max | KSI (MPa)-38 / (260) Max | 30 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Invar 36 | 1.3912 | K93600 | K93603 |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our modern manufacturing facilities are strategically positioned in the UAE, enabling us to keep a large inventory of more than 16,000 tons of top-quality materials on hand and in stock. We are committed to providing outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your requirement.
Invar 36 Sheets and Plates are widely employed in applications demanding minimal thermal expansion and exact dimensional control. They play a vital role in aerospace tooling, satellite components, and cryogenic equipment where precision is essential. This alloy is also applied in precision instruments, laser systems, optical devices, and seismic measurement tools. The electronics and telecommunications sectors rely on it for lead frames, thermostatic components, and support structures. Invar 36 is genuinely a versatile material that satisfies the requirements of numerous high-tech applications.
