Al Vishwas Nickel Alloysis a reputable manufacturer and supplier of top-grade alloys, with expertise in Jethete M152 sheets and plates in Dubai, UAE. Celebrated for outstanding strength and resistance to high temperatures, Jethete M152 is an excellent option for aerospace, industrial, and power generation uses. At Al Vishwas Nickel Alloys, we are dedicated to providing precision-engineered solutions, following international standards to satisfy varied client needs. Backed by unmatched expertise and a customer-focused approach, we guarantee on-time delivery and superior quality for all your alloy requirements.
| Standard Specification : | ASTM A666 / ASME SA666, Jethete M152 (BS S151/ S159) | MSRR 6503 | AMS 5719 | DTD 5066 | WS 1.4933 | AECMA FE-PM37 | UNS S64152 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| C | Si | Mn | P+S max | Cr | Mo | Ni | N | V |
| 0.08-0.13 | 0.35 max | 0.50-0.90 | P 0.030 S 0.025 | 11-12.5 | 1.50-2.0 | 2-3 | 0.02-0.04 | 0.25-0.40 |
| Grade | Treatment | Tensile Strength Mpa | Yield Strength Mpa | Elongation % | Hardness HB | Ruling Section |
| S151A S151D | Softened Finally Heat Treated | 930-1130 | 780 | 14 | 311max 286-311 | – 150mm |
| S159A S159D | Softened Finally Heat Treated | 1100-1300 | 900 | 8 | 311 max 321-388 | 50mm |
| AMS 5719 AMS 5719 | Annealed Hardened & Double Templerd | 1069 min | 896 | 12 | 311 341-375 | – – |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Sheets and Plates in Dubai, UAE, delivering advanced solutions for every piping requirement you may have. Our modern manufacturing facilities are strategically positioned in the UAE, enabling us to keep a large stock of more than 16,000 tons of top-grade materials on hand at all times. We are committed to supplying outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your requirement.
Jethete M152 sheets and platesare extensively utilized in sectors that demand outstanding strength, thermal resistance, and long-lasting performance. Typical uses cover aerospace parts like turbine blades, jet engine components, and fasteners, where performance at high temperatures is essential. Within the power generation industry, they serve in gas and steam turbine components. Industrial uses encompass high-stress tooling, die-casting molds, and fasteners built for demanding environments. Thanks to their resistance to creep and corrosion, combined with superior mechanical properties, Jethete M152 is well suited for uses that require dependability and performance in extreme conditions.
