Al Vishwas Nickel Alloys is a reliable manufacturer and supplier of premium Nickel Alloy 200 Pipe Fittings in Dubai, UAE. Recognized for providing dependable and corrosion-resistant piping solutions, the company offers fittings that bring together outstanding strength, durability, and dimensional accuracy. Our Nickel Alloy 200 Pipe Fittings are produced using advanced technology to guarantee steady performance in challenging industrial settings. With a firm dedication to quality, on-time delivery, and customer satisfaction, Al Vishwas Nickel Alloys caters to industries including chemical processing, marine, oil and gas, and power generation, delivering trustworthy solutions for essential piping and fluid-handling systems.
Nickel Alloy 200 Pipe Fittings consist mainly of high-purity nickel (99% minimum) along with minor amounts of iron, manganese, and carbon, delivering exceptional corrosion resistance in reducing and mildly oxidizing conditions. These fittings display superior tensile strength, strong ductility, and dependable fatigue resistance, guaranteeing lasting performance under high-pressure and challenging conditions. The material additionally provides excellent thermal stability, solid weldability, and resistance to stress corrosion cracking. Nickel Alloy 200 Pipe Fittings preserve their mechanical integrity and durability in severe industrial settings, making them well-suited for chemical, marine, and high-temperature processes.
| Pipe Fittings Specifications | ASTM B366/ ASME SB366 |
|---|---|
| Nickel Alloy Pipe Fittings size | Seamless Butt Weld Fittings : 1/2″ – 10″ Welded Butt Weld Fittings : 1/2″ – 48″ |
| Alloy Pipe Fittings Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
| Nickel Buttweld Fittings Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| Buttweld Pipe FittingsType | DN15-DN1200 |
| ASTM B366 Buttweld Fitting Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASTM B366 Grade Pipe Fitting |
| Size Range | ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM B366 Buttweld Fitting |
| ASTM B366 Buttweld Fittings Manufacturing process | Push, Press, Forge, Cast, etc. |
| Nickel Buttweld Pipe Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| SA 366 Pipe Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | Alloy 90º Elbows, 45º Elbows, Tees, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
| – | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
|---|---|---|---|---|---|---|---|---|---|---|
| Nickel 200 | 99.0 Min | 0.15 Max | – | 0.35 Max | 0.1 Max | 0.4 Max | – | 0.01 Max | 0.25 Max | – |
| Nickel 201 | Balance | 0.15 Max | – | 0.35 Max | 0.35 Max | 0.40 Max | – | 0.01 Max | 0.25 Max |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
|---|---|---|---|---|
| 8.9 G/Cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nickel Alloy 200 Pipe Fittings in Dubai, UAE, delivering advanced solutions for every piping requirement you have. Our cutting-edge manufacturing facilities are strategically positioned in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of top-grade materials on hand and ready to ship. We are committed to providing outstanding products and services, guaranteeing dependability and excellence for customers around the world.
Reach out to us for a fast quote tailored to your requirement.
Nickel Alloy 200 Pipe Fittings are extensively employed in sectors that demand corrosion-resistant and high-strength piping solutions. They find frequent use in chemical processing facilities, seawater handling systems, marine engineering, oil and gas pipelines, and power generation units. These fittings are also applied in heat exchangers, evaporators, condensers, and fluid-handling systems throughout industrial operations. Their outstanding corrosion resistance and mechanical properties render them well suited for food processing, pharmaceutical equipment, and specialized industrial manufacturing. In summary, Nickel Alloy 200 Pipe Fittings deliver safe, durable, and efficient performance in challenging environments, offering dependable connections in critical piping systems.
