Al Vishwas Nickel Alloys, headquartered in Dubai, UAE, distinguishes itself as a leading manufacturer and supplier of high-performance nickel-based materials designed for demanding industrial environments. Among their notable offerings is the Nimonic 80A Bar, a superior nickel-chromium alloy recognized for its outstanding strength, corrosion resistance, and high-temperature stability. Through a dedicated emphasis on precise manufacturing, stringent quality control, and customer-focused solutions, Al Vishwas Nickel Alloys serves a wide range of industries, such as aerospace, power generation, petrochemicals, automotive, and advanced engineering. The company ensures that its Nimonic 80A Bars meet strict international standards, delivering reliable performance in applications requiring superior mechanical and thermal durability.
The Nimonic 80A Bar consists chiefly of nickel and chromium, along with additional titanium, aluminum, and trace elements that enhance its precipitation hardening properties. This alloy is recognized for its remarkable resistance to oxidation and corrosion at high temperatures. From a mechanical perspective, Nimonic 80A offers high tensile strength, superb creep resistance, and exceptional thermal stability, preserving its structural integrity even at temperatures as high as 815°C. It also features good fatigue resistance and dimensional stability when subjected to cyclic loading. Its distinctive combination of hardness, toughness, and high-temperature performance makes it well-suited for parts exposed to severe thermal and mechanical stresses.
| Standards : | Nimonic 80A Rod, Bar : BS 3076 HR1, ASTM B 637, AECMA PrEn2188, AECMA PrEn2189, AECMA PrEn 2190, AECMA PrEn 2396, AECMA PrEn2397, AIR 9165-37 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Grade | Al | B | C | Cr | Co | Cu | Fe | Mn | Ni | P | Si | S |
| Nimonic 80A | 1 – 1.8 | 0.008 max | 0.1 max | 18 – 21 | 0.2 max | 0.2 max | 3 max | 1 max | Balance | 0.045 max | 1 max | 0.015 max |
| Grade | Condition | Ultimate Tensile Strength MPA | Yield Strength MPA | Elongation on 4D (min) | Hardness min |
| Nimonic 80A | Solution Annealed & Precipatation Treated (aged) | 994 | 616 | 20 | 300 HV |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic 80A Bar in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our modern production facilities are strategically situated in the UAE, enabling us to keep an extensive inventory of more than 16,000 tons of top-quality materials on hand and ready in stock. We are committed to providing exceptional products and services, guaranteeing dependability and excellence for our clients worldwide.
Reach out to us for a fast quote tailored to your requirement.
Nimonic 80A Bar is used across a range of industries that require materials able to withstand intense heat, stress, and corrosive environments. Within the aerospace field, it serves in turbine blades, fasteners, afterburner parts, and engine hardware. Power generation plants rely on this alloy for gas turbine components, heat-resistant fasteners, and structural parts subjected to high temperatures. The automotive sector likewise takes advantage of Nimonic 80A, applying it to high-performance engine valves.
