Al Vishwas Nickel Alloys stands as a top manufacturer and supplier of premium Rene 41 Foil in Dubai, UAE. Well known for supplying high-performance nickel-based superalloy products, the company offers foils that unite outstanding strength, heat resistance, and corrosion resistance. Our Rene 41 Foils are precision-engineered through advanced production methods, guaranteeing uniform thickness, dimensional accuracy, and superior reliability in challenging environments. With a firm dedication to quality, on-time delivery, and customer satisfaction, Al Vishwas Nickel Alloys serves industries including aerospace, power generation, and high-temperature manufacturing, supplying materials that satisfy the demanding requirements of advanced engineering applications.
Rene 41 Foil consists mainly of nickel, combined with cobalt, chromium, molybdenum, titanium, and aluminum, delivering outstanding strength at high temperatures along with resistance to oxidation. The alloy’s precisely designed composition guarantees excellent tensile strength, strong creep resistance, and reliable fatigue behavior at raised temperatures. Its microstructure offers high toughness and stability during thermal cycling, all while preserving dimensional integrity. Rene 41 Foils can endure severe thermal and mechanical stress, which makes them well suited for applications requiring both substantial mechanical strength and lasting reliability in harsh, high-temperature industrial settings.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our modern manufacturing facilities are strategically situated in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of top-quality materials on hand and ready for immediate supply. We are committed to providing outstanding products and services, guaranteeing dependability and excellence for our clients around the world.
Reach out to us for a fast quote tailored to your needs.
| Grade | UNS | Workstoff | AMS | GE |
| Rene 41 | N07041 | 2.4973 | AMS 5545, AMS 5712, AMS 5713, AMS 5800 | GE B50TF109, GE B50TF76 |
Rene 41 Foils see extensive use across industries that call for materials capable of withstanding high temperatures, resisting corrosion, and delivering high strength. They are frequently employed in aerospace parts like turbine blades, discs, and combustion chambers, where outstanding mechanical behavior under extreme heat is essential. Such foils also find application in power generation equipment, including gas turbines and jet engines, as well as in specialized industrial manufacturing operations that demand heat-resistant alloys. Rene 41 Foils offer toughness, dimensional stability, and dependable operation despite severe thermal and mechanical stresses, which makes them well suited for use in challenging settings where both performance and long service life are vital.
