Home > Rene 41 Sheets and Plates
Al Vishwas Nickel Alloysremains a trusted name in the manufacturing and supply of high performance nickel alloys in Dubai, UAE. Recognized for its precision and quality, the company focuses on delivering premium products like René 41 Sheets and Plates. Crafted from high strength, heat resistant alloys, these sheets and plates are well suited for aerospace, chemical and industrial uses. Al Vishwas Nickel Alloys is dedicated to excellence, guaranteeing sustainability and reliability for its customers worldwide.
Rene 41 sheets and platesare composed chiefly of nickel, along with added cobalt, chromium and molybdenum for outstanding thermal and corrosion resistance These materials display superb mechanical properties, including high tensile strength, resistance to abrasion and remarkable stability at elevated temperatures Benefits of Rene 41 include mechanical holding power loyalty under extreme temperature conditions, superb oxidation resistance and durability in tough environments, guaranteeing dependable performance in demanding industries such as aerospace, automotive and power a they are in it.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our cutting-edge manufacturing facilities are strategically situated in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of top-quality materials on hand and ready to ship. We are committed to providing outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your needs.
Rene 41 sheets and platesare extremely valuable in applications that demand outstanding resistance to heat and oxidation. Since they can endure temperatures up to 980°C (1800°F), they are commonly employed in aerospace uses, including gas turbine engines, afterburners, and exhaust components These materials are found in rocket engines, medical devices , industrial -and furnace. The considerable strength and corrosion resistance of René 41 make it perfect for applications subjected to intense thermal and mechanical stresses.
