Al Vishwas Nickel Alloys, a well-regarded manufacturer and supplier based in Dubai, UAE, provides premium **Tantalum R05240 Sheets and Plates** engineered for demanding industrial applications. Celebrated for their outstanding corrosion resistance, high purity, and exceptional thermal stability, these sheets and plates are made using advanced techniques and stringent quality control. Al Vishwas Nickel Alloys caters to industries requiring durable, high-performance materials able to withstand aggressive chemical environments, elevated temperatures, and exacting fabrication requirements. With a dedication to technical know-how, timely delivery, and customer satisfaction, the company ensures that its Tantalum R05240 Sheets and Plates deliver enduring performance, superior material integrity, and reliable service.
Tantalum R05240 Sheets and Plates are manufactured from high-purity tantalum, generally holding at least 99.9% Ta, which delivers superb chemical inertness and corrosion resistance. The alloy has very low concentrations of impurities such as oxygen, nitrogen, hydrogen, and carbon, yielding remarkable ductility, formability, and weldability. Regarding mechanical characteristics, R05240 offers high tensile strength, superb thermal stability, and an exceptionally high melting point, which makes it well suited for extreme temperatures and chemically harsh conditions. Its low reactivity and steady mechanical behavior make it ideal for producing essential industrial parts that demand durability, precision, and enduring reliability.
| Standard Specifications | ASTM B708, ASME SB708 / ASTM F 560 |
| Thickness | 0.5 mm – 30 mm |
| Width | 10mm – 2500mm |
| Length | As Your Required |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Types | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Purity | ≥99.9% or 99.95% |
| Grade | R05200, R05400, R05255, R05252, R05240 |
| C | O | N | H | Fe | Mo | Nb | Ni | Si | Ti | W | Ta |
| 0.010 | 0.015 | 0.010 | 0.0015 | 0.010 | 0.020 | 0.100 | 0.010 | 0.005 | 0.010 | 9.0 – 11.0 | Remainder |
| Dimension | Ultimate Tensile Strength, min, psi (MPa) | Yield Strength, min, psi (MPa) (2 % Offset) | Elongation, min, % |
| < 0.125″ (3.175mm) | 70000 (482) | 60000 (414) | 15 |
| ≥0.125″ (3.175mm) | 70000 (482) | 55000 (379) | 20 |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Tantalum R05240 Sheets and Plates in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our modern manufacturing facilities are strategically situated in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of top-quality materials always available on hand. We are committed to supplying outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your requirement.
Tantalum R05240 Sheets and Plates are widely applied across industries demanding outstanding corrosion resistance, high purity, and superior thermal stability. Within chemical processing, they serve in reactor linings, heat exchangers, and numerous components that need to endure harsh environments. Furthermore, these sheets and plates play a vital role in the aerospace and medical sectors, where dependability and performance are critical. Their distinctive characteristics render them ideal for use in electronics, nuclear reactors, and other advanced-technology industries, guaranteeing they satisfy the demanding requirements of contemporary engineering and manufacturing.
