Located in Dubai, UAE, Al Vishwas Nickel Alloys distinguishes itself as a premier manufacturer and supplier of high-quality Tantalum R05252 Sheets and Plates, engineered to perform in the most demanding industrial environments. Employing advanced manufacturing techniques and stringent quality controls, the company crafts sheets and plates known for their outstanding corrosion resistance, elevated melting point, and notable ductility. Al Vishwas Nickel Alloys offers Tantalum R05252 Sheets and Plates in an assortment of thicknesses, dimensions, and finishes customized to satisfy specific project requirements. Serving industries such as chemical processing, aerospace, electronics, and medical, the company is recognized for supplying reliable, high-performance tantalum products that conform to rigorous international standards.
Tantalum R05252 Sheets and Plates consist of high-purity tantalum (99.95% or greater), sometimes with trace elements such as oxygen added to enhance performance. This distinctive makeup gives them outstanding resistance to corrosion from acids, alkalis, and oxidizing settings. From a mechanical standpoint, R05252 Sheets and Plates display superb ductility, a high melting point, good thermal conductivity, and strong mechanical strength even under elevated temperatures. Their ability to withstand aggressive chemicals, high temperatures, and oxidizing conditions makes them ideal for demanding industrial applications requiring durability, reliability, and lasting performance.
| Standard Specifications | ASTM B708, ASME SB708 / ASTM F 560 |
| Thickness | 0.5 mm – 30 mm |
| Width | 10mm – 2500mm |
| Length | As Your Required |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Types | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Purity | ≥99.9% or 99.95% |
| Grade | R05200, R05400, R05255, R05252, R05240 |
| C | O | N | H | Fe | Mo | Nb | Ni | Si | Ti | W | Ta |
| 0.010 | 0.015 | 0.010 | 0.0015 | 0.010 | 0.020 | 0.100 | 0.010 | 0.005 | 0.010 | 9.0 – 11.0 | Remainder |
| Dimension | Ultimate Tensile Strength, min, psi (MPa) | Yield Strength, min, psi (MPa) (2 % Offset) | Elongation, min, % |
| < 0.125″ (3.175mm) | 70000 (482) | 60000 (414) | 15 |
| ≥0.125″ (3.175mm) | 70000 (482) | 55000 (379) | 20 |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Tantalum R05252 Sheets and Plates in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our modern manufacturing facilities are strategically positioned in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of high-quality materials on hand and ready for immediate supply. We are committed to providing outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your requirement.
Tantalum R05252 Sheets and Plates are widely employed across industries requiring exceptional corrosion resistance, high-temperature stability, and chemical inertness. Within chemical processing, they serve in reactors, heat exchangers, and storage tanks that manage strong acids and harsh chemicals. The aerospace and electronics industries depend on them for high-performance parts, capacitors, and protective shielding. Furthermore, the medical sector takes advantage of their biocompatibility, rendering them appropriate for numerous applications where safety and dependability are of the utmost importance.
