Al Vishwas Nickel Alloys, a leading manufacturer and supplier based in Dubai, UAE, focuses on premium **Tantalum Sheets and Plates** engineered to satisfy the rigorous requirements of modern industrial environments. Celebrated for their outstanding corrosion resistance, thermal stability, and material purity, these products are produced with advanced technology and stringent quality control measures. Al Vishwas Nickel Alloys serves industries that rely on trustworthy, high-performance materials able to withstand aggressive chemicals, extreme temperatures, and exacting fabrication demands. Committed to customer satisfaction, technical excellence, and timely delivery, the company ensures that its Tantalum Sheets and Plates deliver enduring performance and outstanding engineering value.
Tantalum Sheets and Plates are manufactured from high-purity tantalum, usually containing a minimum of 99.9% Ta, which guarantees exceptional chemical inertness and corrosion resistance. The material features very low concentrations of impurities such as oxygen, nitrogen, carbon, and hydrogen, resulting in superb ductility, weldability, and formability. From a mechanical perspective, tantalum demonstrates high tensile strength, exceptional thermal stability, and an extraordinarily high melting point, which makes it well-suited for demanding, high-temperature applications. Its minimal reactivity and capacity to preserve structural integrity even within aggressive chemical environments enable efficient fabrication of essential industrial components.
| Standard Specifications | ASTM B708, ASME SB708 / ASTM F 560 |
| Thickness | 0.5 mm – 30 mm |
| Width | 10mm – 2500mm |
| Length | As Your Required |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Types | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Purity | ≥99.9% or 99.95% |
| Grade | R05200, R05400, R05255, R05252, R05240 |
| C | O | N | H | Fe | Mo | Nb | Ni | Si | Ti | W | Ta |
| 0.010 | 0.015 | 0.010 | 0.0015 | 0.010 | 0.020 | 0.100 | 0.010 | 0.005 | 0.010 | 9.0 – 11.0 | Remainder |
| Dimension | Ultimate Tensile Strength, min, psi (MPa) | Yield Strength, min, psi (MPa) (2 % Offset) | Elongation, min, % |
| < 0.125″ (3.175mm) | 70000 (482) | 60000 (414) | 15 |
| ≥0.125″ (3.175mm) | 70000 (482) | 55000 (379) | 20 |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Tantalum Sheets and Plates in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our cutting-edge manufacturing facilities are strategically situated in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of top-quality materials on hand and ready for immediate supply. We are committed to providing outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your needs.
Tantalum Sheets and Plates are widely used across industries requiring outstanding corrosion resistance, high purity, and remarkable temperature tolerance. Within chemical processing plants, they are frequently used for reactor linings, heat exchangers, and equipment that handles harsh acids. Their distinctive characteristics make them well-suited for numerous applications, such as aerospace, electronics, and medical devices, where dependability and performance matter greatly. Through the use of Tantalum Sheets and Plates, businesses can secure the durability and productivity of their operations, even in the harshest conditions.
