Al Vishwas Nickel Alloys, headquartered in Dubai, UAE, is a well-regarded manufacturer and supplier of Titanium Gr 5 Sheet and Plate. Recognized for their remarkable strength, low weight, and exceptional corrosion resistance, these sheets and plates are engineered to satisfy strict industrial standards. Al Vishwas’s Titanium Gr 5 products offer reliable performance in vital applications, guaranteeing durability and accuracy in tough environments. They find broad use across sectors like aerospace, marine, chemical processing, and power generation, delivering enduring structural integrity, resistance to extreme conditions, and superior quality for specialized engineering requirements.
Titanium Gr 5 Sheet and Plate is produced from a titanium alloy containing 6% aluminum and 4% vanadium, which delivers an outstanding strength-to-weight ratio together with impressive corrosion resistance. This material features high tensile strength, excellent fatigue resistance, and outstanding performance even under elevated temperatures. Its mechanical characteristics include superb formability, weldability, and toughness, making it ideal for intricate fabrication and industrial operations. Titanium Gr 5 Sheets and Plates stay stable in demanding environments, withstand chemical attacks, and guarantee dependable long-term performance, offering safety and durability in critical applications where conventional materials may fall short.
| Specifications | : | ASTM / ASME SB265 |
| Size | : | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | : | 0.1mm to 12 mm Thk |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Grade 5 Sheets and Plates in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our modern manufacturing facilities are strategically situated in the UAE, enabling us to keep an extensive inventory of more than 16,000 tons of top-quality materials on hand in stock. We are committed to supplying outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your requirement.
Titanium Gr 5 Sheet and Plate are widely applied in aerospace components, marine structures, chemical processing equipment, heat exchangers, pressure vessels, and power generation systems. They work well for structural panels, aircraft parts, turbine components, and specialized industrial machinery demanding high strength and corrosion resistance. On top of that, these materials serve medical devices, defense applications, and offshore platforms thanks to their dependability and toughness under extreme conditions. These sheets and plates deliver a lightweight but robust option, enhancing operational efficiency and service life.
