Al Vishwas Nickel Alloys, headquartered in Dubai, UAE, is a first-rate manufacturer and supplier focused on high-performance Titanium Tubes, ideally suited for demanding industrial environments. Celebrated for their remarkable strength, corrosion resistance, and lightweight qualities, these Titanium Tubes are engineered to satisfy international quality standards and serve a wide range of uses. Al Vishwas Nickel Alloys takes pride in precision engineering, guaranteeing steady dimensional accuracy and dependable products for sectors such as aerospace, marine, chemical processing, and medical equipment manufacturing. Driven by a firm dedication to innovation and customer satisfaction, the company supplies Titanium Tubes that deliver enduring service and trustworthy performance in mission-critical scenarios.
Titanium Tubes are usually manufactured from commercially pure grades like Grade 2 or from alloyed grades such as Ti-6Al-4V, which contains aluminum and vanadium to enhance strength. They offer a remarkable strength-to-weight ratio, together with high tensile and yield strength, and outstanding corrosion resistance in seawater, acidic settings, and oxidizing conditions. These tubes are biocompatible, non-magnetic, and remain stable even under high temperatures. They also perform well in fatigue resistance, creep resistance, and formability, which makes them well-suited for both structural and pressure-bearing applications across a broad range of industries.
| Specifications (ASTM/ASME) | ASTM B381/381M R56400, ASME SB381/381M R56400 |
| Tube Size | 1/16 OD to 2 OD, Od to 50mm OD |
| Types we Offer | Titanium Instrumentation Fittings Ti Grade 5 Double Ferrule Fittings Ti Grade 2 Twin Ferrule Fittings Ti-6al-4v Eli Titanium Ferrule Fittings Pure Titanium Pneumatic Fittings Ti Grade 6 Flare Fittings Cp Gr2 Ti JIC Fittings Tial6v4 Instrumentation Fittings Ti Alloy Grade 5 Hydraulic Hose Fittings ASTM B348 Grade 5 Compression Fittings Cp Grade 1 Double Ferrule Fittings ASME SB 348 Grade 2 Push-To-Connect Fittings Grade 5 Compression Fittings Ti Gr2 Hydraulic Fittings |
| Material Grades | Titanium Gr.5 – UNS R56400, Titanium Gr 2 – UNS R50400 |
| THREAD | BSPT, UNF, BSP, NPT, ISO, SAE, etc. |
| Forms | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
| Working Pressure | Upto 2000 to 6000 PSI |
| Medium – Pressure Gaugeable | Pressure Ratings: Up to 20 000 psig (1378 bar) Temperature Ratings: Up to 1000°F (537°C) |
| High-Pressure | Pressure Ratings: Up to 60 000 psig (4134 bar) Temperature Ratings: Up to 1000°F (537°C) |
| Body Type | FORGED, BAR STOCK |
| PTFE Standards | ASTM D1710, ASTM D3294 |
| Surface | Export bright finish, short blasted finish, electroplated finish |
| Applications Temperature | 150-400°C |
| Ends | Welding, Threaded, JIC |
| Packing Details | As per your detailed request Normally carton size – 21*16*14CM/31*21*16CM/36*45*50CM Normally wooden box size – 38*27*17CM Normally 1piece/ opp, 10-20pcs/ carton |
| Element | Ti | C | Fe | H | N | O | Al | V |
| Titanium | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
At Al Vishwas Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Tube Fittings in Dubai, UAE, delivering advanced solutions for every one of your piping requirements. Our modern production facilities are strategically situated in the UAE, enabling us to keep an extensive stock of more than 16,000 tons of high-quality materials ready and available. We are committed to supplying outstanding products and services, guaranteeing dependability and excellence for our worldwide customers.
Reach out to us for a fast quote tailored to your needs.
Titanium Tubes see strong demand throughout numerous industries that need materials which are durable, low in weight, and corrosion-resistant. Within aerospace, they serve in hydraulic systems, airframes, and engine components. In healthcare, they are used for surgical instruments, orthopedic implants, and prosthetics owing to their biocompatibility. The marine and offshore sectors rely on them for heat exchangers, condensers, and gear that deals with seawater. Chemical processing facilities count on these tubes for piping, reactors, and systems subjected to corrosive conditions, guaranteeing safety and efficiency throughout their operations.
